Suitable For Type NGEF 10HP

Get a Price/Quote

Product Details:

Thickness Approx. 10 mm
Surface Treatment Brass terminals polished; base untreated
Sealed NO
Product Type Terminal Socket
Material Plastic base with brass terminals
Application Electrical motor connections
Contact Resistance Low resistance brass connections
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Suitable For Type NGEF 10HP Product Specifications

Sealed NO
Surface Treatment Brass terminals polished; base untreated
Contact Resistance Low resistance brass connections
Product Type Terminal Socket
Style Round design with hexagonal arrangement
Terminal Socket 6-terminal socket
Diameter Approx. 100 mm
Application Electrical motor connections
Rated Voltage Suitable for 10HP motors
Fittings Screw-on brass terminals
Thickness Approx. 10 mm
Material Plastic base with brass terminals
Weight Lightweight - Approx. 150 grams
Insulation Resistance High - suitable for industrial use
Color Black
Warranty As per manufacturer warranty

Product Description

Product Details

DRG NO.	OD	E	D	H	T
EF - 8070	88	73	9X6	37	M6
